Midsole Beam
Midsole Beam
It bears the weight of the vehicle body and cargo, as well as longitudinal traction and impact forces during operation.
Midsole Beam
Structural Features
The center beam may be either through-type or non-through-type. In a non-through-type center beam, the beam extends only to the two bolster beams; the portion of the center beam between the bolster beams and the end beams is referred to as the traction beam.
To accommodate greater loads, the center and side beams may be designed as fish-belly girders, with a larger cross-sectional area at the center than at the ends; this design is known as a fish-belly bogie frame.
Cast steel front and rear draft sill brackets are riveted to both ends of the center beam to facilitate the installation of the coupler and buffer assembly.
Functional role
It bears the weight of the vehicle body and cargo, as well as longitudinal traction and impact forces during operation.
In the fish-belly underframe, the design of the center beam helps to distribute the load and enhance the underframe’s load-carrying capacity.
| Product Series | Longitudinal beam |
|---|---|
| Applications | It bears the weight of the vehicle body and cargo, as well as longitudinal traction and impact forces during operation. |
| Customization | OEM / ODM, drawing-based production, factory-direct supply and engineering support |
| Source Product ID | Yilin original product 1491491688637018112 |
